• Allows to treat the cattle gently and without injuries.
• An essential tool for the marking, counting, classifying, sanitary and veterinary treatment of animals.
• An additional advantage is that it meets the needs of our age in terms of occupational safety, for circumstances prevailing on the working area are fully regulated and controlled during treatments, for the safety of animals and people as well.
• Great advantage of the corral is the mobility, so that the place of treatment of the animals can adapt to the current requirements. It is not necessary to drive or transport the animals possibly for tens of kilometers, which would tire them. This way the corral can be easily fitted in pasture garden grazing system.
• The corral panels are hot-dip galvanized, which provides protection against corrosion in unfavorable weather conditions as well, so the panels can be stored outdoor.
• The flat surface designated for installation does not require special preparation, the corral can be set on both natural open ground and solid floor too.
• The connection of the corral elements is ensured with chains, which allows quick and easy mounting of the corral, with quick and stable fixing. Therefore, the equipment can be easily moved to another location in just a few hours.

Contains:

• 4 pieces of crowding tube curved panel (KM-MV-4-81)
• 1 sweep bow gate (KM-MV-4-62)
• 1 premier panel with alley frame (KM-MV-4-34)
• 3 pieces of bottom connection pipe for crowding tub / sweep radius bar (KM-MV-4-74)
• 13 pieces of cattle corral panel (KM-MV-4-5801)
• 1 panel with gate ( Gate 2m ) (KM-MV-4-48)
• 1 panel with gate  (KM-MV-4-12)
• 1 alley frame (KM-MV-4-27)
• 1 alley frame with gate (KM-MV-4-92)
• 1 two-way sorting gate (KM-MV-4-29)

The number of corral panels can be extended or reduced depending on the number of animals!

The price of the sorting system does not include the crush or head bail / head gate! Check out our range of cattle treatment crushes and head bails / head gates!

Accessories: 58 pieces of 5 mm hot-dip galvanized chain, equipped with a carabiner.

Surface treatment: Hot-dip galvanized.

Weight: 1247 kg
